背景抑制型漫反射光電開關HRTR 3B/2.7

• Basic data
  • Series3
  • Operating principleScanning principle with background suppression
• Optik
  • Operating range, white 90%0.005 ... 0.4 m
  • Operating range, gray 18%0.01 ... 0.3 m
  • Operating range, black 6%0.015 ... 0.2 m
• Optics
  • Operating range limit0.005 ... 0.4 m
  • Light sourceLED, Red
• Timing
  • Switching frequency1.000 Hz
• Electrical equipment
  • Performance data
    • Supply voltage10 ... 30 V, DC
  • Outputs
    • Number of digital switching outputs1 Piece(s)
    • Switching output 1
      • Switching elementTransistor, NPN
      • Switching principleLight switching
• Connection
  • Connection 1
    • TypeCable
    • Cable length2.000 mm
    • Number of conductors4 Piece(s)
• Mechanical data
  • DesignCube
  • Dimension11 mm x 32 mm x 17 mm
  • Housing materialPlastic, PC-ABS
  • Lens cover materialPlastic (PMMA)
  • Net weight10 g
• Operation and display
  • Operational controlsMultiturn potentiometer
• Environmental data
  • Ambient temperature, operation-25 ... 55 °C
• Certifications
  • Protection classIP 67
  • Safety classIII
  • CertificationsCE, c UL US
  • Standards appliedIEC 60947-5-2
